SH-750 / SH-754 tractor
|
|
| Model No.︰ | SH-750 / SH-754 |
| Brand Name︰ | - |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
Model
|
|
SH-750
|
SH-754
|
|
Type
|
/
|
4×2
|
4×4
|
|
dimension(L*W*H)
|
mm
|
4052×1900×2650
|
4052×1900×2650
|
|
Wheel base(F/R)
|
mm
|
1350/1525
|
1450/1525
|
|
Wheel base(F/R)adjust
|
/
|
step adjustment / step adjustment
|
Non-adjustment/step adjustment
|
|
Minimum groundclearance
|
mm
|
440
|
340
|
|
Minimum using weight
|
kg
|
2740
|
3010
|
|
Counterweight(Max)
|
kg
|
Front 270/Rear 480
|
Front 270/Rear 480
|
|
Gear shift(Forward/Reverse/Climb)
|
/
|
8/2
|
8/2
|
|
Max traction
|
kN
|
13.75
|
15.0
|
|
Engine
|
Model
|
/
|
LR4B5-T90
|
LR4B5-T90
|
|
Inspiratory way
|
/
|
Natural
|
Natural
|
|
Cylinder no
|
pcs
|
4
|
4
|
|
Cylinder bore*stroke
|
mm
|
108×135
|
108×135
|
|
Rated power
|
kW
|
55
|
55
|
|
Rated turning
|
r/min.
|
2200
|
2200
|
|
Steering
|
/
|
Hydraulic
|
Hydraulic
|
|
Brake
|
/
|
Mechnical operate
|
Mechnical operate
|
|
Clutch
|
/
|
Dry type,
single disc, action/double
|
Dry type,
single disc, action/double
|
|
Minimum turning radius
|
m
|
4.6±0.2
|
4.9±0.3
|
|
Tyre (F/R)
|
/
|
6.5-20/14.9-30
|
8.3-24/14.9-30
|
|
Tyre pressure(F/R)
|
kPa
|
200～250/118～137
|
118～137/118～137
|
|
Suspension
|
/
|
Rear 3 point
|
Rear 3 point
|
|
Suspension type
|
/
|
2
|
2
|
|
Frame Maximum lifting force
|
kN
|
12.405
|
12.405
|
|
Adjustment method
|
/
|
Force bit control and Floating control
|
Force bit control and Floating control
|
|
Hydraulic output
|
/
|
Without
|
Without
|
|
PTO shaft
|
/
|
Semi-independent
|
Semi-independent
|
|
PTO shaft turning speed
|
r/min
|
1000（Optional 760）
|
1000（Optional 760）
|
|
PTO shaft power
|
kW
|
46.8
|
46.8
|
|
implements
|
/
|
/
|
/
|
| |
/
|
/
|
/
|
|
|
|
|
| Advantages︰ | 1:Low Price High Efficiency
2:ECand EPA are Available
3:Excellent After Sale Service
4:YTO Engine Designed For the South American Soil
5:Gallery of Implements for the tractors :From end loader ,hydraulic backhoe front,plough, rotary cultivator,seed drill,single shaft or hydraulic dump trailer .PTO shaft driving water pump or generator,chipper ,ditching machine mower,and snower blower. |
|
|
