KT-1604 tractor
|
|
| Model No.︰ | KT-1604 |
| Brand Name︰ | - |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
Item
|
Unit
|
KT-1604
|
|
Net Power of Engine
|
kW(HP)
|
118（160）
|
|
Driving Method
|
|
4x4
|
|
Dimension, Length/Width (tread) /Height (Cab Top)
|
mm
|
5830/2420（Double tire3510）/3010
|
|
Wheelbase
|
mm
|
3080
|
|
Wheelbase of Front Wheel
|
mm
|
1928-2240
|
|
Wheelbase of Rear Wheel
|
mm
|
1952-2568
|
|
Minimum Ground Clearances
|
mm
|
415
|
|
Minimum Steering Circle Radius
|
mm
|
6900
|
|
Minimum Working Weight
|
kg
|
7300
|
|
Front Counterweight≤
|
kg
|
500
|
|
Rated Traction Force
|
kN
|
36
|
|
Power Output Shaft
|
Model
|
|
Independent Rear-mounted
|
|
Standard RPM
|
r/min
|
540/1000
|
|
Maximum Lifting Force
|
kN
|
36
|
|
forward gear
|
Low RPM
|
The number of stalls
|
|
7
|
|
Driving Speed
|
km/h
|
2-17
|
|
High RPM
|
The number of stalls
|
|
7
|
|
Driving Speed
|
km/h
|
3-30
|
|
Reverse Shift
|
The number of stalls
|
|
7
|
|
Driving Speed
|
km/h
|
2-17
|
|
Specification of Tire
|
Front Wheel
|
|
14.9-28R1
|
|
Rear Wheel
|
|
18.4-38R1（Double tire）
|
|
Diesel Engine
|
Nominated Power/RPM
|
kW/r/min
|
118/2000
|
|
Nominated Working Condition Fuel Oil Consumption Rate
|
g/kW·h
|
≤230
|
|
|
|
|
| Advantages︰ | 1. Add the attachment conveniently
With the integrated frame, independent and extensible PTO, the tractor can add the attachment of loading, digging, bulldozing, and lifting conveniently. Expand the function of the tractor and improve the utilization ratio of the tractor.
2. Adopt the mature technology conveniently
In terms of the parts, the tractor can adopt the mature technology in heavy truck and construction machinery, such as the technologies of disc brake, wet clutch, synchronizer, and oil and gas power. With the development advantage of other industries, the company accelerates to improve the technology of the tractor.
3. Expand the product model conveniently
The spare parts come from the mature products such as the heavy truck, construction machinery and agricultural machinery, which have respective series and specification. The product development cycle will be greatly shorted if the company optimizes these parts to form the products of different horsepower. The company has developed 8 models, more than 30 types of large tractor of 110-270 horsepower in the past 4 years. Six modes have been produced in large quantity.
4. Satisfy the individual requirement of user conveniently
Adjust the speed ratio of the transmission to get the different speed for each gear, which can meet the agricultural requirement in various regions; adjust the speed ratio of the final drive case to meet the requirement of output speed standard in different countries. The company also can select the function modules according to the user’s requirement to produce special tractor.
5. Organize the mass production conveniently
The module structure adopts the common parts. The company can adopt the social resources and the manufacturing platform of XCMG, and organizes the mass production of large tractor without any great fixed investment.
6. Repair conveniently
The module structure is convenient for the engineer to shoot the trouble and repair the machine.
7. Shangchai six cylinder engine is designed with fully enclosed cab, air heater, 14+7 shifts of transmission, shifting synchronizer, integrated frame, driving system with modularized structure，CARRARO front axle，rear axle for engineering machinery, after the double configuration, caliper disc brake, revolution for power output shaft of dual revolution 540/1000r/min, fully hydraulic front wheel steering, three groups of single/dual action hydraulic output, plough depth control method by position、floating control, and suspension mechanism of rear-mounted Category Ⅲ,and front balance weight is 500KG.. |
|
|
Product Image
|
|
|
