Model: 3WZ-1000-14
Mating power of tractor: ≥80hp
Working pressure: 0.3-0.5 MPa
Rotary speed: 550-650 r/min
Spraying Width: 14m
Spraying volume of nozzle: 1.17 or 1.55 or 1.94 (±8%)
Quantity of nozzle: 28
Nozzle interval width: 500mm
Nozzle type: Fan-type Nozzle 110°, anti-drip device (other type is optional)
Material of spraying pipe: stainless steel
Tank Volume: 1000L
Hydraulic Pump: diaphragm pump (flow: 140L/min.)
Overall dimensions: 3450*2950*1830mm (transporting status)
Net weight: 450kg
Spraying arm: folding by hand
