CT18 series mini excavator
|
|
| Model No.︰ | CT18 series |
| Brand Name︰ | - |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
SPECIFCATIONS
|
Model
|
CT18-7
|
CT18-7B
|
|
Operating weight
|
1.710 KG
|
1.760 KG
|
|
Travel speed
|
2.15/3.83km/h
|
2.15/3.83km/h
|
|
Bucket Capacity
|
0.05/0.06m3(SAE)
|
0.05/0.06m3(SAE)
|
|
Tracking force
|
11.54kn
|
11.54kn
|
|
Engine power
|
16KW@2.200RPM
|
16KW@2.200RPM
|
|
gradeability
|
30°(58%)
|
30°(58%)
|
|
Swing speed
|
10.9RPM
|
10.9RPM
|
|
Bucket digging force
|
11.44 kn
|
11.44 kn
|
|
Ground Pressure
|
29KPa
|
29KPa
|
|
Arm digging force
|
8.04 kn
|
8.04 kn
|
DIMENSIONS
|
Model
|
CT18-7
|
CT18-7B
|
|
Upperstructure width
|
1.050 mm
|
1.050 mm
|
|
Undercarriage width
|
1.080 mm
|
1.080 mm
|
|
Overall Height with cabinet
|
2.455 mm
|
2.455 mm
|
|
Rear swing radius
|
1.200 mm
|
1.200 mm
|
|
Clearance under counter weight
|
467 mm
|
467 mm
|
|
Tumbler Distance
|
1.185 mm
|
1.185 mm
|
|
Ground clearance
|
212 mm
|
212 mm
|
|
Overall length for transportation
|
3.790 mm
|
3.790 mm
|
WORKING RANGE
|
Model
|
CT18-7
|
CT18-7B
|
|
MAX digging radius
|
3.720 mm
|
3.720 mm
|
|
MAX digging radius at ground lever
|
3.640 mm
|
3.640 mm
|
|
MAX digging depth
|
2.100 mm
|
2.100 mm
|
|
MAX digging height
|
3.150 mm
|
3.150 mm
|
|
MAX dumping height
|
2.070 mm
|
2.070 mm
|
|
MAX dozer cutting depth
|
190 mm
|
190 mm
|
|
MAX dozer lifting height
|
210 mm
|
210 mm
|
HYDRAULIC SYSTEM
|
Model
|
CT18-7
|
CT18-7B
|
|
MAIN PUMP
|
AXIAL PISTON PUMP & GEAR PUMP
|
AXIAL PISTON PUMP & GEAR PUMP
|
|
|
CONSTANT POWER VARIABLE DISPACEMENT WITH GEAR PUMP OVERRIDE CONTROL
|
CONSTANT POWER VARIABLE DISPACEMENT WITH GEAR PUMP OVERRIDE CONTROL
|
|
|
FLOW/PRESSURE 45.8*2+37 l/MIN @ 2.200 RPM / 21MPA
|
FLOW/PRESSURE 45.8*2+37 l/MIN @ 2.200 RPM / 21MPA
|
|
PILOT PUMP
|
TYPE
|
TYPE
|
|
|
GEAR PUMP
|
GEAR PUMP
|
|
|
FLOW/PRESSURE 22*2 L/min @ 2.200 rpm / 16 mpa
|
FLOW/PRESSURE 22*2 L/min @ 2.200 rpm / 16 mpa
|
|
|
SWING MOTOR
|
SWING MOTOR
|
|
|
ATTACHMENTS
|
ATTACHMENTS
|
|
|
OVER LOAD PRESSURE
|
over load pressure
|
|
BOOM / ARM
|
BUCKET 20 MPA
|
BUCKET 20 MPA
|
|
|
|
|
| Advantages︰ | CT18-7 Excavators
Laidong diesel engine Power 16KW/2200rpm In conformity with the EU III emission control regulations Imported hydraulic components, guarantee for 3 yrs under normal use and maintenance South Korea made gasoline tank On-line digital monitoring and control system GPS satellite position(optional)and remote diagnose system(optional) Rubber pedrail(optional, or steel pedrail), no damage to the ground of road full opened engine hood and easy up-forward-lifted cab Cold&warm air conditioner(optional)
CT18-7B Excavators
Originally imported Japanese Yanmar 3NTV82A diesel enging In conformity with the EU III emission control regulations Imported hydraulic components, guarantee for 3 yrs under normal use and maintenance , South Korea made gasoline tank On-line digital monitoring and control system GPS satellite position(optional)and remote diagnose system(optional) Rubber pedrail(optional, or steel pedrail), no damage to the ground of road full opened engine hood and easy up-forward-lifted cab Cold&warm air conditioner(optional) |
|
|
Product Image
|
|
|
