Model
|
4GL-80
|
4GL-100
|
4GL-120
|
|
Mating power
|
5.5-11hp
|
5.5-12hp
|
12-22hp
|
|
Packing size (L*W*H)
|
1100*750*650mm
|
1250*750*650mm
|
1450*750*650mm
|
|
Net weight
|
60kg
|
70kg
|
90kg
|
|
Operator
|
1
|
|
Productivity
|
0.13-0.2ha./h.
|
0.17-0.23ha./h.
|
0.26-0.54ha./h.
|
|
Reaping width
|
800mm
|
1000mm
|
1200mm
|
|
Min. stubble reaping height
|
30mm
|
|
Working speed
|
4-6.5km/h.
|
|
Laying form
|
Side-delivery
|
|
Loading quantity
|
90 sets/20GP, 244 sets/40HQ
|
75 sets/20GP, 216 sets/40HQ
|
72 sets/20GP, 192 sets/40HQ
|
|
|
|
|
| Advantages︰ | 1. Usage: Attached with the tractor or the power tiller, it could finish the work of reaping of the paddy, wheat, sesame, soybean and pasture etc.
2. Features: walking type and self-propelled.
3. Function: Reaping and side-delivery.
4. Advantages: Small size, light weight, less fuel consumption, flexible, easy operation and low stubble.
5. Mating power: 5.5-22hp walking tractor or power tiller. |
|
|
Product Image
|
|
4GL-80 Reaper
4GL-100 Reaper
4GL-120 Reaper
4GL-100 Swather
|
|
|
|
