1GN series rotary tiller
|
|
| Model No.︰ | 1GN-120,1GN-160 |
| Brand Name︰ | MINGSIN |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
Model
|
1GN-120
|
1GN-125
|
1GN-140
|
1GN-150
|
1GN-160
|
|
Working Width(cm)
|
120
|
125
|
140
|
150
|
160
|
|
Working Depth(cm)
|
Dry land 8-14 Paddy field 14-16
|
|
Type of
|
IT225
|
|
|
|
|
|
No.of b1
|
24
|
24
|
30
|
34
|
38
|
|
Overall
|
90*154*109
|
90*136*109
|
90*169*109
|
90*170*109
|
90*188*109
|
|
Weight
|
170
|
182
|
214
|
240
|
260
|
|
Rotary speed
|
540
|
|
Rotary speed
|
199(Tractors'PTO is 540 rmps).213(Tractors'PTO is 720rmps)
|
|
working
|
1.0-3.0
|
|
Producting
|
0.4-0.47
|
0.4-0.47
|
0.33-0.5
|
0.36-0.56
|
0.38-0.62
|
|
Linkage
|
three point mounted
|
|
Matched
|
13.2-18.4
|
13.2-18.4
|
18.4-22
|
22-29.4
|
29.4-36.7
|
|
|
|
|
| Advantages︰ | Rotary tiller driven by the tractor's out-put sgaft.During operation,the soil is crumbled by the rotating and forwarding of the blades fixed on the sgaft.It also can be used as shallow tilling and covering on the stalinized soil to prevent the salt in the soil.Themachine will fulfill the working of cleaning stubbles and weeds,turning and covering green fertilizer vegetable fields,etc. After tillage,the land surface is leveling and smooth,the cover burden is closely,working efficiency is high and oil consumption is lower. |
|
|
Product Image
|
|
|
