1BJX series middle-duty disc harrow
|
|
| Model No.︰ | 1BJX series |
| Brand Name︰ | MINGSIN |
| Country of Origin︰ | - |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
Model
|
1BJX-1.7
|
1BJX-2.0
|
1BJX-2.2
|
1BJX-2.4
|
|
Working width(M)
|
1.7
|
2.0
|
2.2
|
2.4
|
|
Working depth(Cm)
|
14-18
|
|
Dia. Of Disc(Mm)
|
560
|
|
Disc space(Mm)
|
230
|
|
Qty. of Disc
|
16
|
18
|
20
|
22
|
|
Productivity(Ha/h)
|
1.3
|
1.5
|
1.6
|
1.8
|
|
Overall size(Mm)
|
1960*1880*1317
|
1980*2240*1317
|
1980*2470*1317
|
2780*2570*1340
|
|
Weight(Kg)
|
400
|
434
|
463
|
604
|
|
Linkage
|
Three point- mounted
|
|
Matched power(Hp)
|
45-55
|
50-65
|
55-65
|
65-75
|
|
|
|
|
| Advantages︰ | The 1BJX series Middle-duty Disc Harrow's front gangs are assembled with scalloped disc, and rear gangs with plain disc. The harrows are adopted a whole frame made of quadrangular steel tubes by welding, So their structures are simple and reasonable, strong and durable. Their processes are perfect. The bearing is ball bearing with sphere-outside and square-inside, its rated load is large, trailing resistance is small, sealing is good. They're convenient to operate and maintain. Efficient in pulverizing and penetrating into the soil and leaves the land with a smooth, even tilth. All these satisfy the agricultural requirements of intensive cultivation.
The 1BJX series Disc Harrow are suitable for pulverized and loosening clods on sticky heavy clay soil after ploughing and for planning the land before sowing. On cultivated land, the machines can make soil and fertilizer mix up, and clear away the stump of plants and be used instead of plough on light or medium soil and preparing seed bed for planting.
The 1BJX series Middle-duty Disc Harrow could be used with from 35HP to 120HP type tractors. |
|
|
