1LY series reversible disc plough
|
|
| Model No.︰ | 1LY series |
| Brand Name︰ | MINGSIN |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
|
Model
|
1LY(SX)-325
|
1LY(SX)-425
|
1LY(SX)-525
|
1LY(SX)-625
|
|
Working width (m)
|
0.75
|
1.00
|
1.25
|
1.50
|
|
Working depth (cm)
|
25
|
25
|
25
|
30
|
|
Qty. of Disc (pcs)
|
3
|
4
|
5
|
6
|
|
Dia. Of Disc (mm)
|
660
|
660
|
660
|
660
|
|
Weight (kg)
|
560
|
660
|
760
|
880
|
|
Linkage
|
Three point-mounted
|
|
|
Matched Power (hp)
|
50-65
|
65-90
|
90-100
|
100-120
|
|
|
|
|
| Advantages︰ | This series reversible disc plough is lower cast and higher volume output. The working speed is 8-10km/h.
The reversible plough can be mounted to 15-120 HP tractors with 2 ways of reverse-mechanical (J), and hydraulic (Y). Hydraulic reversed plough can be adjusted for the different width and different tractors, the. Hydraulic system is automatically and the operation is smooth without any troubles. |
|
|
Product Image
|
|
|
