CT260-8 excavator
|
|
| Model No.︰ | CT260-8 |
| Brand Name︰ | - |
| Country of Origin︰ | China |
| Unit Price︰ | - |
| Minimum Order︰ | - |
|
|
|
|
|
|
|
SPECIFCATIONS
|
Model
|
CT260-8
|
|
Operating weight
|
24900 KG
|
|
Engine power
|
133 km/2000 h
|
|
Travel speed
|
5.5 Km/3.1 rpm
|
|
Ground pressure
|
52 kpa
|
|
Bucket digging force
|
220 kN
|
|
Fuel tenk capacity
|
410 L
|
|
Bucket capavcity
|
1.2 M3
|
|
Swing speed
|
11.5 rpm
|
|
Gradeability
|
35°(70%)
|
|
Arm digging force
|
164 kn
|
|
Hydraulic tank capacity
|
230 L
|
DIMENSIONS
|
Model
|
CT260-8
|
|
Overall Length
|
10005 mm
|
|
Overall height
|
3150 mm
|
|
Overall width
|
2980 mm
|
|
Cab height
|
3010 mm
|
|
Ground clearance of counterweight
|
1045 mm
|
|
Min.ground clearance
|
489 mm
|
|
Rear-end swing radius
|
2940 mm
|
|
Tumblers distrances
|
3860 mm
|
|
Undercarriage length
|
4590 mm
|
|
Track gauge
|
2380 mm
|
|
Track shoe width
|
600 mm
|
|
Upper structure width
|
2700 mm
|
WORKING RANGE
|
Model
|
CT260-8
|
|
MAX digging radius
|
10240 mm
|
|
MAX digging radius on ground
|
10060 mm
|
|
MAX digging depth
|
6527 mm
|
|
MAX vertical wall digging depth
|
6140 mm
|
|
MAX digging height
|
9980 mm
|
|
MAX dumping height
|
7170 mm
|
|
Min swing radius
|
3404 mm
|
HYDRAULIC SYSTEM
|
NAME
|
PARAMETER
|
|
Hydraulic Pump
|
Main Pump
|
TYPE
|
2 Piston Motor
|
|
Rate of Flow
|
2*225L/min
|
|
Pilot Pump
|
TYPE
|
1 Piston Motor
|
|
Rate of Flow
|
21L/min
|
|
Hydraulic Motor
|
Walk Motor
|
2 Piston Motor
|
|
Rotary Motor
|
1 Piston Motor
|
|
Spill Valve
|
Work oil-way
|
34.3MPa
|
|
Turn oil-way
|
25.5MPa
|
|
Walk oil-way
|
34.3MPa
|
|
Pilot oil-way
|
3.9MPa
|
|
Hydraulic Power
|
Without
|
|
Hydraulic Cylinder
|
Arm
|
Quantity
|
2
|
|
Cylinder diameter
|
130mm
|
|
Shaft Cylinder
|
90mm
|
|
Bomm
|
Quantity
|
1
|
|
Cylinder diameter
|
140mm
|
|
Shaft Cylinder
|
90mm
|
|
Bucket
|
Quantity
|
1
|
|
Cylinder diameter
|
130mm
|
|
Shaft Cylinder
|
90mm
|
| |
|
|
|
|
|
|
|
|
| Advantages︰ | CT260 series excavator is a new model which adopts the features of modern hydraulic excavators, and it can meet various jobs.
The CT260 series excavator is designed according to principles of high efficiency, reliable performance, strong power. It adopts originally imported engines and hydraulics. The new technology application on boom/stick/chassis/upper structure/swing system make them more fit for hard jobs such as mining jobs. CT260 series excavators meets the jobs demands such as earthmoving, river clearance, projects construction and especially for large mines. |
|
|
Product Image
|
|
|
