SH-450 / SH-454 tractor
|
|
| Model No.︰ | SH-450 / SH-454 |
| Country of Origin︰ | China |
|
|
|
|
|
|
|
|
Model
|
|
SH-450
|
SH-454
|
|
Type
|
/
|
4×2
|
4×4
|
|
dimension(L*W*H)
|
mm
|
3700×1620×2130
|
3700×1620×2130
|
|
Wheel base(F/R)
|
mm
|
1200-1500(regular1300)
/1200-1500(regular1300)
|
1250/1200-1500(regular1300)
|
|
Wheel(F/R)adjustment
|
/
|
Step adjust/step adjust
|
Can not /step adjust
|
|
mini ground clearance
|
mm
|
400
|
325
|
|
Mini using weight
|
kg
|
1850
|
2120
|
|
Counterweight(max)
|
kg
|
F106/R180
|
F127/R180
|
|
gearshift(F/R/Climb)
|
/
|
8/4/0 or 8/8/0
|
8/4/0 or 8/8/0
|
|
Max traction
|
kN
|
≥8.5
|
≥11.3
|
|
Engine 1
|
Model
|
/
|
SL3105ABT
|
|
|
Inspiratory
|
/
|
Natural
|
|
|
Cylinder no
|
pcs
|
3
|
|
|
Cylinder diamter × stroke
|
mm
|
105×117
|
|
|
Rated power
|
kW
|
33.1/45HP
|
|
|
Rated turning speed
|
r/min
|
2200
|
|
|
Engine 2
|
Model
|
/
|
QC495/T45
|
|
|
Inspiratory
|
/
|
Natural
|
|
|
Cylidner no
|
pcs
|
4
|
|
|
Cylinder bore×stroke
|
mm
|
95×105
|
|
|
Rated power
|
kW
|
33.1
|
|
|
Rated turning speed
|
r/min
|
2400
|
|
|
Steering
|
/
|
Hydraulic
|
Hydraulic
|
|
Brake
|
/
|
Wet disc brake,
Mechanical operate
|
Wet disc brake,
Mechnical operating
|
|
Clutch
|
/
|
Dry single action /double
|
Dry single action/double action
|
|
Mini turning radius
|
m
|
3.1±0.3
|
3.4±0.3
|
|
Tyre (F/R)
|
/
|
6.0-16/12.4-28
|
8.3-20/12.4-28
|
|
Tyre pressure(F/R)
|
kPa
|
200~250/80~120
|
90~120/80~120
|
|
Suspension
|
/
|
Rear 3 point
|
Rear 3 point
|
|
Suspension type
|
/
|
1
|
1
|
|
Frame max lift force
|
kN
|
7.5
|
10.13
|
|
Adjustment
|
/
|
Force bit control
|
Force bit control
|
|
Hydraulic output
|
/
|
M20×1.5
|
M20×1.5
|
|
PTO shaft
|
/
|
Semi-independent
|
Semi-independent
|
|
PTO shaft turning speed
|
r/min
|
540/760
|
540/760
|
|
PTO shaft power
|
kW
|
28.2
|
28.2
|
|
|
|
|
| Advantages︰ | 1. Fujian Lijia SL3105ABT engine, direct injection, water-cooling or firewood QC495/T45 engine, direct injection, the mandatory water cooled;
2. Patented design flow line hood, nice; 3. Two-wheel drive;
4. Class adjustable front and rear;
8 +4regular shift or 8 +8 shuttle shift;
5. Clutch shift;
6. With differential lock;
7. Dry dual role clutch;
8. Dual chip oil bath disc brakes, the brakes only need a small pedal efforts even in theafter repeated heavy job to maintain high operating efficiency;
9. Hydraulic steering, light sensitive;
10. Power output (540/760 r / min);
11. Adjustable seat;
12. Split floor;
13. Category three point suspension: 1;
14. Force bit aloneadjusting lifters;
15. Front and rear tire :6.0-16 / 12.4-28
16. Paddy field wheel (optional);
17. Maintenance-free storage battery;
18. Optional rear weight;
19. Optional air brakes;
20. GB security guards. |
|
|
