SH-500 / SH-504 tractor
|
|
| Model No.︰ | SH-500 / SH-504 |
| Country of Origin︰ | China |
|
|
|
|
|
|
|
|
Model
|
SH-500
|
SH-504
|
|
Overall size(LxWxH)mm
|
3513 x1750 x 2130
|
3513 x1750 x 2130
|
|
Wheel base(mm)
|
1880
|
1924
|
|
Minimums ground clearance(mm)
|
400
|
325
|
|
Front tire
|
6.00-16
|
8.3-20
|
|
Rear tire
|
12.4-28/14.9-24(optional)
|
12.4-28/14.9-24(optional)
|
|
Drive type
|
4x 2
|
4x 4
|
|
Engine
|
|
|
|
Engine model
|
495BT
|
495BT
|
|
Type of engine
|
vertical, direct injection, water cooled,
4 cylinder,4 Stroke diesel engine
|
|
Capacity of fuel tank(L)
|
38
|
38
|
|
Engine power
|
36.8
|
36.8
|
|
PTO power at rated speed
|
2300
|
2400
|
|
Clutch
|
dry, dual-stage type
|
|
PTO speed
|
540/760rpm
|
|
Gear shift
|
8F+4R/16F+8R(Optional)
|
|
Hydraulic output valve
|
multi-way valve (optional)
|
|
Category of 3-point link
|
rear, category II
|
rear, category II
|
|
Lifting force(at point of 610mm)KN
|
9
|
12
|
|
Speed (Km/h)
|
2.6-34.78
|
2.6-34.78
|
|
|
|
|
| Advantages︰ | SH-500/SH-504 is the tractor which combine original brand with European technology. SH-500 has the features including modern appearance, paint specialization, instrument integration and operation humanized etc. Meanwhile, SH-500 is welcomed by many customers for its fuel-efficient and environment protection.
1,SH-500 has its advantage such as narrow wheel track, high ground clearance, light weight and flexible steering. SH-500 can work not only in small and paddy field but also in large dry land.
2,The engine use ω combustion chamber and 360 burning platform. So it can be burned fully with less retained gas.
3,The four-hole nozzle can supply oil rapidly, and the atomization effect is good.
4,Hydraulic system uses gear pump with optional hydraulic output while increasing the lifting force. |
|
|
